General Cargo Semi Trailer

USD$16,480

The Price Only For Reference, Difference Specification Difference Price !

A general cargo semi trailer is a type of trailer that is designed to transport a wide range of general goods and cargo. These trailers are commonly used in logistics and transportation industries for the efficient movement of goods from one location to another.

Brand: TIMA

Model Number: TIA350GCT

Shipment Time: 15-25 working days

Contact Now

Product Details

General Cargo Semi Trailer Details

General cargo semi trailers come in various sizes and configurations to accommodate different types of cargo. They are typically equipped with a flatbed or enclosed cargo space, allowing for easy loading and unloading of goods. Some trailers may also have side curtains or sliding doors for added convenience.

Cargo Semi Trailer

General Cargo Semi Trailer For Sale In Chad

General Cargo Semi Trailer Specification

Overall Dimension: 12600x2580x3150mm(LxWxH)

Axle: FUWA/ZY/BPW brand. 3 axle, 3x12000kg

Tire: TRIANGLE brand. 315/80R22.5, 12 pcs.

Support Leg: JOST brand, 28 tons

Tractor Pin: JOST brand, 3.5 inch

Suspension: Air or mechanical suspension

Container Lock: 12 pcs

Leaf Spring: 90x13mmx10pcs

Loading Capacity: 50,000kg

The general cargo trailer specification only for your reference, we also can manufacture general cargo trailer basic on your request.

General Cargo Semi Trailer Main Beam

The general cargo semi trailer main beam adopt the manganese plate, thickness of main beam is bottom 14mm, middle 8mm, upper plate is 12mm. Structure is H model, adopt the automatic submerged welding tech. It is constructed to distribute the weight of the cargo evenly across the trailer and provide structural integrity. The design and dimensions of the main beam may vary depending on the specific trailer model and its intended use.

Cargo Semi Trailer
