20FT 40FT Container Interlink Trailer

20FT 40FT Container Interlink Trailer Details

Container interlink trailers typically have a skeletal structure with a series of twist locks and support beams to secure the containers in place. They are built to withstand the weight and dimensions of standard shipping containers, which come in various sizes, such as 20-foot, 40-foot, and 45-foot containers.

                                           20FT 40FT Container Interlink Trailer For Sale In Malawi

20FT 40FT Container Interlink Trailer Specification

Overall Dimension: 17600x2550x1550mm(LxWxH)

Axle: FUWA/ZY/BPW brand. 4 axle, 4x12000kg

Tire: TRIANGLE brand. 315/80R22.5, 16 pcs.

Support Leg: JOST brand, 28 tons

Tractor Pin: JOST brand, 3.5 inch

Suspension: Air or mechanical suspension

Container Lock: 12 pcs

Leaf Spring: 90x13mmx10pcs

Loading Capacity: 50,000kg

The 20FT 40FT container interlink trailer specification only for your reference, we also can manufacture container interlink trailer basic on your request.

20FT 40FT Container Interlink Trailer Kingpin

These container interlink trailers are equipped with a variety of features to facilitate container handling, such as hydraulic systems for lifting and lowering containers, telescopic chassis to adjust the length according to the container size, and braking systems designed to handle heavy loads. The kingpin adopt the JOST brand, model is heavy duty, max pull loading capacity reach to 90 tons.
