4 Axles Dumper Trailer

4 Axles Dumper Trailer Tire Details

The 4 axles dumper trailer tire is 315/80R22.5, tubeless model. LINGLONG brand. Applying the long-distance SOCT stress optimization control technology system developed by Linglong alone, it has optimized and upgraded various aspects from pattern, structure, adhesive formula, skeleton material and process, etc. The wear consumption is improved by 30%, anti-stone trapping, no groove cracking and more stable product quality control.

                                                           4 Axles Dumper Trailer For Sale In Guinea

4 Axles Dumper Trailer Specification

Overall Dimension: 11500x2520x3550mm(LxWxH)

Axle: FUWA/ZY/BPW brand. 4 axle, 4x16000kg

Tire: TRIANGLE brand. 315/80R22.5, 16+1 pcs.

Support Leg: JOST brand, 28 tons

Tractor Pin: JOST brand, 3.5 inch

Suspension: Air or mechanical suspension

Leaf Spring: TAIYUE brand. 90x16mmx10pcs

Loading Capacity: 80,000kg

The 4 axles dumper trailer specification only for your reference, we also can manufacture dumper trailer basic on your request.

4 Axles Dumper Trailer Support Leg

4 axles dumper trailer support leg is JOST brand, The operation mode can be divided into single-action and linkage. Single-action outrigger refers to the two sides of the separate operation, there are two rocker, each outrigger has a gear box. The linkage outrigger refers to 1 side operation and 2 sides up, only 1 rocker, there is 1 with gear box and 1 without the composition.
