Superlink Flatbed Trailer

About Superlink Flatbed Trailer

The superlink flatbed trailer very popular in logistics company, one time can loading 3 pcs 20FT container or 2 pcs container. And the superlink flatbed trailer adopt the durable parts for the main loading parts, such as heavy duty FUWA 13 tons axle, 12R22.5 long distance transportation tire and quick-acting ABS and WABCO braking system.

                                                    Superlink Flatbed Trailer For Sale In Mozambique

Superlink Flatbed Trailer Specification

Overall Dimension: 17500x2580x3200mm(LxWxH)

Axle: FUWA brand. 4 axle, 4x13000kg, FUWA brand

Tire: TRIANGLE brand. 315/80R22.5, 16 pcs.

Support Leg: JOST brand, 28 tons

Tractor Pin: JOST brand, 3.5 inch

Brake Valve: WABCO brand

Suspension: mechanical suspension

Leaf Spring: 90x16mmx10pcs

Loading Capacity: 70 tons

The superlink flatbed trailer for sale specification only for your reference, we also can manufacture flatbed trailer basic on your request.

Superlink Flatbed Trailer Chassis Detail

The superlink flatbed trailer chassis adopt the # structure design, ensure load-bearing capacity while reducing tare weight. The # shape refers to the cross-section of the main beams that form the chassis frame. These beams are typically made of high-strength steel and are arranged in a way that provides optimal strength and rigidity. The advantage of this design is that it distributes the weight of the cargo evenly across the chassis, allowing for efficient load distribution and maximizing the load-bearing capacity of the trailer.

Superlink Flatbed Trailer Brake System Detail

The superlink flatbed trailer brake system mainly including the WABCO emergency brake valve and ABS brake system. The combination of the WABCO emergency brake valve and the ABS brake system enhances the safety and performance of the superlink flatbed trailer. It ensures reliable braking in emergency situations and helps prevent wheel lock-up, promoting better stability and control during braking maneuvers.
